The HPDM-2300 is an ultra-high power density multisector integrated motor drive for primary propulsor applications and series-hybrid power generation on electric aircraft and ships. Based on the same core technology as our lower power products, this unit has a specific power of >10 kW/kg and features the highest level of fault tolerance and reliability with its twelve independent drive sectors. The HPDM-2300 is capable of bidirectional power flow and can be used as a motor or generator.
The HPDM-2300 provides industry-leading power density and efficiency using our advanced winding, electromagnetics, thermals, and power electronics core technology.
Featuring twelve drive sectors, the HPDM-2300 ensures fault tolerance and continuous operation in the event of an electrical or cooling failure.
The HPDM-2300 delivers a high torque output of 12,200 Nm at a max shaft speed of 1800 RPM, making it ideal for direct-drive applications, eliminating the need for a gearbox and simplifying system integration.
Onboard accelerometers and temperature sensors provide life status and predictive maintenance for bearings, winding, and other critical components.
